The 25226-2 series terminal block bus bars are designed to be used with the MS27212 terminal blocks. They consist of parallel plates of conductors bonded together and separated by a thin layer of insulation to provide low inductance, high capacitance, and ease of assembly. Ideal for system integration where high power switching, such as IGBTs, is involved.This bus bar (EDMO# 25226-2-10) connects to terminal blocks with ten, 6-32-sized holes with a 0.594 hole spacing from center to center. It is also made of cadmium-plated copper.
| Unit Qty |
1 |
|---|
